Name: Indoor Rental LED Screen - Broadcast and Television Studio LED Wall Solution
Brand: SHENZHEN KAILITE OPTOELECTRONIC TECHNOLOGY CO., LTD
SKU: P2.97
Price: 850.00 USD
Availability: InStock

บ้าน ผลิตภัณฑ์หน้าจอ Led เช่าในร่ม

Indoor Rental LED Screen - Broadcast and Television Studio LED Wall Solution

รายละเอียดสินค้า:

สถานที่กำเนิด:	เซินเจิ้นประเทศจีน
ชื่อแบรนด์:	KAILITE
ได้รับการรับรอง:	IOS9001 , IOS2000,FCC,RoHS,CE,CCC
หมายเลขรุ่น:	P2.97

การชำระเงิน:

จำนวนสั่งซื้อขั้นต่ำ:	2 ตารางเมตร
ราคา:	Negotiatable
รายละเอียดการบรรจุ:	กระเป๋าเดินทางสำหรับตู้นำ P2.9 500 * 1,000 มม
เวลาการส่งมอบ:	22-24 วัน
เงื่อนไขการชำระเงิน:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
สามารถในการผลิต:	9000 ตารางเมตรต่อเดือน

ติดต่อ

รายละเอียดสินค้า

บริการโลโก้ฟรี:	ใช่	รายการ:	2.9 มม.
ความหนาแน่นของพิกเซล:	112896จุด/ตร.ม	uasge:	ในร่ม
อัตราการรีเฟรช:	7680เฮิร์ต	รับบัตร:	1 ชิ้น
ตลอดชีวิต:	100,000 ชั่วโมง	จำนวนโมดูล:	2*4 ชิ้น
การทำงาน:	เล่นวิดีโอ/รูปภาพ/คำ	มาตรฐานแอลอีดี:	SMD1515
ระยะการรับชม:	3ม.-10ม	อัตรา:	0.0001
สีชิปหลอด:	ครบสี	แรงดันไฟฟ้าขาเข้า:	AC110-220v±10%
การเข้าถึงบริการ:	หลัง

Indoor Rental LED Screen - Broadcast and Television Studio LED Wall Solution

Product Overview

Broadcast and television production environments demand LED displays that meet specific technical requirements that consumer and commercial-grade displays cannot satisfy. The Indoor Rental LED Screen delivers the combination of high refresh rate, wide viewing angle, and color consistency that broadcast studios require.

The 1920-3840Hz refresh rate eliminates scan lines and flicker that appear on standard-refresh-rate displays when captured by professional broadcast cameras—a critical quality issue that can render an entire shoot unusable. The 160-degree viewing angle in both axes is essential for studio environments where the display is viewed from multiple positions simultaneously by camera operators, talent, and floor crew.

The P2.6 model, with its 2.604mm pixel pitch and 147,456 dots per square meter, delivers the resolution needed for 4K and HD broadcast production where cameras may shoot the LED wall at close range.

Technical Specifications

Parameter	Specification
Pixel Pitch Options	P2.6 / P2.97 / P3.91 / P4.81 (selectable)
Module Size	250 x 250 mm
Cabinet Size	500 x 500(1000) x 84 mm
Cabinet Material	Die Casting Aluminum
Cabinet Weight	7 kg (single hand lift)
Brightness	Greater than or equal to 800 nits
Refresh Rate	1920-3840 Hz
Viewing Angle	H: 160 degrees; V: 160 degrees
Grey Level	12-16 bit
Ingress Protection	IP43
Life Time	Greater than 100,000 hours
Maintenance	Front and Rear maintenance
LED Type	SMD2020
Video Frame Rate	Greater than or equal to 60 Hz
Failure Rate	Less than 0.0002
Application	Stage events, car exhibitions, rental displays, corporate events

Key Benefits

1920-3840Hz refresh rate for broadcast camera compatibility – Eliminates scan lines and flicker artifacts when captured by professional broadcast cameras at any shutter speed
160-degree wide viewing angle for multi-position studio environments – Camera operators, talent, and floor crew all see a consistent, accurate image regardless of position
P2.6 model with 147,456 dots per square meter for 4K broadcast resolution – Highest pixel density delivers detail resolution required for professional broadcast production
12-16 bit grey level for smooth tonal gradation – Fine gradations in dark scenes and skin tones render without visible banding
IP43 rated for studio environment durability – Protection against dust and light water spray for typical studio environments

Applications

Broadcast studio virtual production backgrounds
Television news set LED walls
Live broadcast event production
Film and commercial production with LED volume stages
Corporate broadcast studios for internal and external communications

Why It Works

Broadcast camera compatibility is a specialized requirement that most LED display manufacturers do not design for. Standard LED displays typically have refresh rates of 60Hz or 120Hz—adequate for direct human viewing but inadequate when captured by broadcast cameras at shutter speeds of 1/50 second or faster.

At standard refresh rates, the camera's shutter captures the display's refresh cycle as visible scan lines or banding across the image, which is unacceptable in professional broadcast production. The 3840Hz maximum refresh rate on this display exceeds the requirements of professional broadcast cameras, ensuring that even at the fastest shutter speeds, the display renders as a solid, flicker-free image.

The P2.6 model with 147,456 dots per square meter is equally important for broadcast: at typical virtual production camera distances of 2-3 meters from the LED wall, a coarser pixel pitch would produce visible pixel structure that cameras resolve as distracting moire patterns.

After-sales Service

Your inquiry about our products or pricing will be replied within 24 hours
We provide 2 years warranty and lifelong maintenance
Flexible delivery options to suit your needs
Comprehensive product range including Outdoor LED Display, LED Pharmacy Cross Display, LED Flexible Display, Indoor LED Display, LED Gas Price Signs, and Indoor/outdoor LED Signs

Frequently Asked Questions

Can the product be customized?
Yes, we can customize according to your requirements. We arrange sampling first, confirm details with you, then proceed with production.
Can I place a sample order to test first?
Yes, we will create a sample list according to your needs.
How to install LED displays?
We provide installation manuals and video instructions. Technical drawings are also available upon request.
How to proceed with an order for LED Screen?
1. Share your requirements or application needs
2. We provide quotation based on your requirements
3. Customer confirms design document and places deposit
4. We arrange production
